Main Meditech SVF-7000 Basic / Pro Perimeter
Main Meditech SVF-7000 Basic / Pro Perimeter
For detailed product information, please click on the manufacturer’s logo
Description
Technical Parameter
|
odel Parameter
|
SVF-7000 Basic |
SVF-7000 Pro |
|
DB Value Range displayed |
0~40db |
|
|
Stimulus Intensity Range |
1asb~10000asb |
|
|
Stimulus Size |
Goldmann III |
|
|
Stimulus Color |
White |
|
|
Stimulus Duration Time |
200ms/ Adaptive |
|
|
Max Measurement range |
90° |
|
|
Test Distance |
30cm |
|
|
Test Mode |
Static |
|
|
Stimulus quantity |
456 points |
|
|
Stimulus Plane |
Aspherical surface |
|
|
Background Illumination |
White 31.5 asb ( 10cd/m2 ) |
|
|
Voice Guidance function |
/ |
● |
|
Fixation Deviation Alarm |
/ |
● |
|
Customize test program |
/ |
● |
|
/ |
● |
|
|
Blindzone test program |
/ |
● |
|
Stimulus Source |
LED |
|
|
Chinrest Control |
Touch Screen,Keyboard and mouse control,Button control |
|
|
Head Movement |
||
|
PC Configuration |
CPU:Intel® Processor N100 (6M Cache, up to 3.40 GHz); RAM:4GB; Hara Disk:120GB;
Operation system: Windows 10;
LCD:14 ” Capacitive Touch screen;
Networking: Ethernet & WIFI;
|
|
|
Dimension |
480mm(L)*430mm(W)*528mm(H), 14 kgs | |
|
Packaging |
550mm(L)*480mm(W)*640mm(H), 21 kgs | |
|
Others |
Input Voltage: AC 100 – 240V,50 ~ 60Hz | |
